1. Dual-Action Structure + Hydraulic Drive: Utilizing a dual-action design of “main cylinder + edge-pressing cylinder,” it can simultaneously perform stretching and edge-pressing actions, suitable for deep-drawing processes; the hydraulic system offers fast response, stable pressure, and supports multi-stage speed/pressure adjustment.
2. High Durability: The column and piston rod surfaces are hard chrome plated and high-frequency treated for wear resistance; key components (hydraulic/electrical) are mostly imported brands, ensuring high stability.
3. Intelligent + Safe: Equipped with a PLC control system and touchscreen, featuring safety light curtains, overtravel protection, and other devices for more reliable operation.
4. High Efficiency and Energy Saving: The movable crossbeam supports two speeds: “high speed under no-load + slow speed for working feed,” resulting in low energy consumption and high forming efficiency.
1. Dual-Action Structure + Hydraulic Drive: Utilizing a dual-action design of "main cylinder + edge-pressing cylinder," it can simultaneously perform stretching and edge-pressing actions, suitable for deep-drawing processes; the hydraulic system offers fast response, stable pressure, and supports multi-stage speed/pressure adjustment. 2. High Durability: The column and piston rod surfaces are hard chrome plated and high-frequency treated for wear resistance; key components (hydraulic/electrical) are mostly imported brands, ensuring high stability. 3. Intelligent + Safe: Equipped with a PLC control system and touchscreen, featuring safety light curtains, overtravel protection, and other devices for more reliable operation. 4. High Efficiency and Energy Saving: The movable crossbeam supports two speeds: "high speed under no-load + slow speed for working feed," resulting in low energy consumption and high forming efficiency.
1. 双动结构+液压驱动
• 采用“主缸+压边缸”双动设计，能同时实现拉伸和压边动作，适合深拉伸工艺；液压系统响应快、压力稳定，还支持多段速度/压力调节。
2. 高耐用性
• 立柱、活塞杆表面镀硬铬+高频处理，抗磨损；关键元件（液压/电器）多采用进口品牌，稳定性强。
3. 智能+安全
• 配备PLC控制系统+触摸屏，带安全光幕、超行程保护等装置，操作更可靠。
4. 高效节能
• 活动横梁支持“空载高速+工进慢速”两段速度，能耗低、成型效率高。
主要用于金属薄板的拉伸/成型工艺，覆盖行业包括：
• 五金制品（如不锈钢厨具、卫浴）；
• 汽车/摩托车配件（覆盖件、零件）；
• 家电零件（如外壳、容器）；
• 航空/仪表、化工容器等领域；
• 也可用于塑料、粉末冶金等材料的压制成型。
